Vertical balers

HSM V-Press 818 plus

Vertical balers

185 kN

max: 200 kg

B: 700 mm H: 780 mm L: 1200 mm

B: 1700 mm T: 1046 mm H: 2370 mm

Scroll to the desired section:

Thanks to its low transport height, the HSM V-Press 818 can be easily transported to wherever it needs to be used.

Low installation height and small footprint
To fill the press, the upper half of the doors is folded down
Automatic start of the pressing process after closing the door
Convenient membrane keypad with text display, which shows the current status of the machine
Hand wheel door lock - Easy to handle thanks to counter-rotating thread for quick opening and closing
Massive press ram and extremely robust press plate guidance
HSM TCS (Torsion Control System) for monitoring press ram movement
Manual bale strapping with continuous polyester tape
Suitable for cardboard as well as film

Product attributes	HSM V-Press 610	HSM V-Press 818 plus	HSM V-Press 820 plus
Order number:	6110164	6050414	6043414
Pressing power:	120 kN	185 kN	178 kN
Maximum bale weight:	100 kg	200 kg	250 kg
Bale size (WxHxL):	600 x 600 x 800 mm	700 x 780 x 1200 mm	1000 x 780 x 1200 mm
Loading aperture (WxH):	800 x 495 mm	1195 x 530 mm	1195 x 558 mm
Number of strappings:	3	4	4
Type of consumables:	strapping tape	strapping tape	strapping tape
Motor:	3 kW	4 kW	4 kW
Voltage / Frequency:	400 V / 50 Hz	400 V / 50 Hz	400 V / 50 Hz
Cycle time:	22 s	27 s	23 s
Dimensions of machine (WxDxH):	1198 x 823 x 1986 mm	1700 x 1046 x 2370 mm	1700 x 1075 x 2499 mm
Machine weight:	540 kg	1070 kg	1300 kg

Consumable Materials

Strapping tape WG 40 - 12 Gigant/Dixi 15S/Dixi 16S/Dixi 18S/Dixi 6SL/V-Press 503/V-Press 504/V-Press 605/V-Press 610/V-Press 718 plus C/V-Press 818/V-Press 820/V-Press 825/V-Press 830
