HSM FP 3000 barrel press With a pressing power of 270 kN the HSM FP 3000 is excellently suited... more
HSM FP 3000 barrel press
With a pressing power of 270 kN the HSM FP 3000 is excellently suited for pressing light metal and rolled hoop barrels.
Excellently suitable for light metal and rolled hoop barrels
Volume reduction up to 95 %
Explosion protected model as per EX II Gcb IIBT3
Low installation height and small footprint
Press ram with spikes for opening the barrels and collector tray for residual liquid
Automatic return stroke saves time, overheads and personnel costs
Enclosed on all sides with inspection window for safety and dust reduction
Membrane key-pad with LED for operator safety
Low-maintenance and durable electro-hydraulics
Technical data "HSM FP 3000"
| Order number: | 6820264 |
| EAN: | 4026631077583 |
| Pressing power: | 270 kN |
| Specific pressing power: | 60 N/cm² |
| Driving power: | 7,5 kW |
| Voltage / Frequency: | 400 V / 50 Hz |
| Cycle time when idling vacío: | 33 s |
| Volume throughput in idle operation (theor.): | 6,25 m³/h |
| Loading height: | 1092 mm |
| Loading aperture width x height: | 618 x 1092 mm |
| Width x Depth x Height: | 1168 x 960 x 2892 mm |
| Weight: | 972 kg |
| Press material: | Barrels |
